Sucker Rod Power Tong from China manufacturer - TOPLAND OILFIELD SUPPLIES LTD.

Product Detail

Model No.: No-4

Packing: Standard Packing

Type: Drilling Rig

Means of Transport: Ocean,Land,Air

Delivery Date: According to order

Application: Oil

Sucker rod power tong is used for quick make-up/break-out sucker rod in well service operations.

The tongs have the following features:

Technical Specifications:

Model		XQ28/1.8Y	XQ28/2.6Y
Pipe Size Range Of Master Tong	mm	Sucker rod16,19,22,25 Tubing ɸ48-60	ɸ16,19,22,25,28
Pipe Size Range Of Master Tong	in	Sucker rod 5/8"-1 1/8" Tubing 1 7/8"-2 3/8"	5/8"- 1 1/8"
Pipe Size Rang Of Backup Tong	mm	Sucker rod16,19,22,25,28 Tubing ɸ48-60	ɸ16,19,22,25,28
Pipe Size Rang Of Backup Tong	in	Sucker rod 5/8"-1 1/8" Tubing 1 7/8"-2 3/8"	5/8"- 1 1/8"
High Gear Rated Torque	kn.m	0.7	1
High Gear Rated Torque	ft.lbf	516	737.5
Low Gear Rated Torque	kn.m	1.8	2.6
Low Gear Rated Torque	ft.lbf	1327.6	1918
High Gear Rated Speed	r/min	104	98
Low Gear Rated Speed	r/min	40	32
Rated Operation Pressure	Mpa	10	10
Rated Operation Pressure	Psi	1450	1450
Max. Flow	L/min	65	80
Max. Flow	gpm	17	21
Overall Dimension L X W X H	MM	543 x 334 x 404	670 x 383 x 490
Overall Dimension L X W X H	IN	21.5 x 13 x 15.9	26.5 x 15 x 19
Weight Including Backup Tong	Kg	105	100
Weight Including Backup Tong	lb	231	220
